Side-hung trolley-type single-girder crane

This product consists of a box-shaped main beam, end beams, a trolley, and a running mechanism. The electric hoist is mounted on an angled trolley as the lifting mechanism. The angled trolley is mounted off-center to one side of the main beam and features upper and lower horizontal wheels in a three-point arrangement with the vertical running wheels. The electric hoist has been moved from its traditional position below the main beam to above it, effectively increasing the lifting height. The trolley utilizes a conical motor brake and an open gear transmission. The box-shaped main beam is off-center and features upper and lower horizontal wheels, ensuring safety and reliability while preventing rail gnawing. The trolley is separately driven, with a conical motor brake and an open gear transmission.

Product Features

TThis product consists of a box-shaped main beam, end beams, a trolley, and a running mechanism. The electric hoist is mounted on the angled trolley as the lifting mechanism. The angled trolley is positioned offset to one side of the main beam and operates with upper and lower horizontal wheels, forming a three-point arrangement with the vertical running wheels. The electric hoist has been moved from its traditional position below the main beam to above it, effectively increasing the lifting height.
The trolley is operated by a conical motor brake and an open gear transmission.
The main beam is a box-type structure with offset track and horizontal wheels at the top and bottom, which is safe and reliable and can prevent the rails from being chewed.
The crane is driven separately, with a conical motor brake and open gear transmission. The operating motor can be equipped with a soft starter or variable frequency speed control according to user requirements, ensuring smooth crane startup and safe and reliable operation.
The operation mode is provided with a ground handle or a wireless remote control.
